20 hp explosion proof electric motor 256T frame 3 phase 230/460 volt 3600 rpm
Part# IXHHI20-36-256T Hyundai Electric
This is a new explosion proof severe duty motor for hazardous location applications
Class 1,Div 1, Groups C & D Class II Div 1, Groups E,F&G
Three Year warranty!
Fast Free Shipping via LTL freight truck!
Click Here For Drawing and Data Sheet
HP: 20RPM: 3550Frame: 256TVoltage: 230/460 (Usable at 208V)Amps: 46.5/23.2Efficiency: 91.0%Phase: 3SF: 1.15Shaft: 1 5/8" x 4"Enclosure: Explosion Proof Weight: 350 lbs
